Product Name : FDA Certified CGMP GMP Pharma Water System with Conveyor Part
It is important to control microorganism and bacteria for purified water equipment ,which include as following these aspect:
- The choice of the host material,all of them adopt Stainless Steel 304 ,316L,BPE standard ,the conveyor part is suggest to automatically weld ,orbital welding ,track welding .
- Disinfection Method : Pasteurization and Ozonization .
- Pipeline and Valve : between the pipeline of the used point and valve ,we are accord to 3D regulations to execute to prevent dead water ,pipeline has certain slope .equal to 5‰.
- The welding process: Our factory have automatcial machinery .
- It is important to control flowrate of circulation pipeline.
- The various meters monitor in time ,that know the condition of water quality at any time .
- 3D installation rules
We can choose the different disinfection methods according to condition on sit .
Pharmaceutical water is divided into four part :
| Item | Process | Way |
| 1 | Pre-treatment part | Quartz Sand filter + Activated Carbon filter |
| 2 | Reverse Osmosis Device Part | Normal & High temperature Membrane |
| 3 | Disinfection Part | Hot water ,Ozone, |
| 4 | Distribution Part | U type , |
Main Components of Water System
| Item | Parts Name | Brand |
| 1 | RO membrane | DOW ,HYDRANAUTICS |
| 2 | Valve | Diaphragm Valve ,Burket, Kinglai ,Yuan'an |
| 3 | Flowmeter | KROHNE |
| 4 | Pump | Grundfos ,CNP |
| 5 | Pressure Gauge | WEIKI |
| 6 | PLC | SIEMENS |
FAQ:
1.Question: How to package and ship water treatment equipment ?
Answer : Inside with wrapping film ,The wooden case cover outside .
2.Question : How to install purified water system ?
Answer : 1.According to our operation instruction,Layout in English 2. By video of Wechat and Whatsapp . 3. Send our engineer to client on-site.
3.Question: Are there training from CHONGYANG Water ?
Answer:Sure , The customer can send their engineer to factory for training that it is no fee .
4.Question: How many countries have been sent your reverse osmosis system to ?
Answer : A lot of , Iran ,Bangladesh ,Egypt,Pakistan,Malaysia etc.
Product Tags:
|
|
FDA Pharma Water System CGMP GMP 2000L/H Images
|
